SNAP-ON SOLUS EDGE SCAN TOOL MODEL EESC320
PRODUCT FEATURES • Hand held portable diagnostic scan tool • Rechargeable battery pack and charger • Keyless adapter for OBD-II vehicle applications • Carrying case • 1-year manufacturer’s warranty • Global OBD vehicle communications 1995 to current • Domestic vehicle-specific communications for codes, data functional tests, relearns and adaptations for model year 1980 – 2015 vehicles • Asian Import vehicle-specific communications for codes, data, functional tests, relearns and adaptations for model year 1983 – 2015vehicles • Optional European vehicle-specific communications for codes, data, functional tests, relearns and adaptations for model year 1992 – 2015vehicles • Fast-Track® Troubleshooter database with over 6.8 million diagnostic tips, tests and timesavers • Capable of accessing web-based SureTrack® expert information system with common replaced parts data, vehicle-specific tips and real fixes • WiFi access to SureTrack data
DISPLAY DEVICE • 8 inch, color touchscreen, 800x480 LCD display • SMX operating system • Operates through 4-way keypad or touchscreen • User-programmable ‘S’ button navigation hotkey • Automatic power-on feature when connected to vehicle • Internal battery can recharge through vehicle data cable • Upgradeable software on Micro SD card
ADVANCED SCAN TOOL DATA ACQUISITION CAPABILITIES • Selective display of 1, 2 or 4 live data graphs • Display up to 7 live data points in digital mode • Record, playback, pause data review • Display live data parameters concurrently during functional tests • Display four live data parameters while recording all available data parameters in the background • PC-interface capability through ShopStream Connect™ to display, save and print scanner results • User data storage on Micro SD card • User activated cursors for frame of reference to compare pinpoint data values • User-selectable PID trigger function
GLOBAL OBD VEHICLE COMMUNICATION SOFTWARE • Communicates with 1995-newer OBD compatible vehicles • Establishes communication with the appropriate vehicle protocol automatically
ACCESS ALL TEN MODES OF OBD-II • Mode 1: graphs or displays current data • Mode 2: retrieves freeze frame data • Mode 3: monitors diagnostic trouble codes • Mode 4: reads and clears emissions related data • Mode 5: oxygen sensor monitoring • Mode 6: non-continuously monitored systems • Mode 7: diagnostic trouble codes detected during last drive • Mode 8: bi-directional controls (where available) • Mode 9: displays important vehicle information • Mode 10: permanent codes
GM VEHICLE COMMUNICATION SOFTWARE 1980 – 2015 • Enhanced OBD-I, OBD-II & Generic OBD-II modes • Engine/Powertrain, Transmission, ABS, Airbag, Body, Instrument Panel, Vehicle Theft Deterrent, Tire Pressure Monitor, Transfer Case, and Trailer Brake Control system diagnostics, Code Scan, Clear All Codes, Seats, Parking Brake, Steering Angle, Auto-ID • Front View Camera • Radio/HVAC • Headlamp Modules • Auxiliary Body Controls • Air Suspension • Active Grille Air Shutter Module • Object Detection • Telematics • Seat Modules • Rollover Sensor for Safety Systems • 6.6L Crankshaft Position (CKP) Sensor Test • Passenger Presence • Diesel Power Balance Test • Vehicle Theft Deterrent Codes, Data & Indicator Status • Radio Systems Codes, Data & Test Including VIN Write • HVAC Actuator & Door Recalibration • 6.6L Turbo Tests • Theft Deterrent, Keyless Entry and Remote Function Actuation • ABS & Air Bag GM symptom codes • Brake Pedal Pressure (BPP) Relearn • Engine Bi-Directional Testing, incl. EVAP Monitor Test and EVAP System Testing, Output Controls, Injector Balance, ICB, IAC, EGR, Crank Pos Relearn • Particulate Filter Replacement & Fuel Filter Life Reset Function – Diesel engines where applicable • Transmission Bi-Directional Testing, incl. Solenoid Tests, Trans Shifting and Adaptive Resets • ABS Diagnostics and Brake Bleeding, incl. Bosch, DelcoMoraine, Teves • Dash and Rear Integration Modules • BCM Bi-Directional Testing, incl. Door Locks, Lights, Chimes, Horn, Wipers • 2004 and newer Key Fob programming
